ATESS Automatic Transfer Switch
The ATESS ATS50 is a dedicated automatic transfer switch designed specifically for the HPS50 hybrid solar inverter. It provides reliable, hands-free switching between the utility grid and a diesel generator, ensuring continuous power availability in commercial and hybrid solar setups.
Key Features
Automatic Power Management
- Monitors grid stability and automatically switches to generator when needed
- Returns to grid power once stability is restored
- Ensures uninterrupted operation for critical loads
HPS50 Compatible
- Designed for seamless integration with HPS50 inverters
- Supports remote generator control for full automation
- Flexible management options simplify hybrid system setup
Safety & Protection
- Lightning protection: Type II
- Protection degree: IP20
- Output, grid, and DG breakers rated at 250 A
- Optional zero-export function for grid-tied solar systems
Technical Specifications
- Rated voltage: 400 V
- Rated current: 144 A
- Rated frequency: 50/60 Hz
- Rated power: 50 kW
- Operating temperature: -25°C to +55°C
- Relative humidity: 0–95% non-condensing
- Dimensions (W/H/D): 600 × 1500 × 450 mm
- Weight: 77 kg
- Communication: RS485 / CAN
How It Works
The ATS50 acts as an intelligent bridge in hybrid solar systems, managing power transitions between the grid and a diesel generator. When the grid fails or drops below set parameters, the ATS signals the generator to start and switches the supply to generator output. Once grid power is restored, it seamlessly reverts back, keeping connected loads continuously powered.
This automated switching improves reliability, protects sensitive equipment, and eliminates the need for manual intervention, making it ideal for commercial and industrial hybrid energy installations.
Applications
- Commercial hybrid solar energy systems
- HPS50 inverter installations with backup generators
- Critical load applications requiring continuous power
- Remote or off-grid facilities requiring automated source management
ATESS ATS50 Automatic Transfer Switch for HPS50 – Automatically switch between grid and diesel generator for reliable hybrid solar power. 50kW, 400V, 144A, IP20, Type II lightning protection, RS485/CAN communication, hands-free operation.
