Tiger Neo 590Wp TOPCon N-Type Mono Silver FramePart No: JKM590N-72HL4-V-SF Panels – Monocrystallines
Rating: 590W
Efficiency: 22.8%
Width: 1,134mm
Height: 2,278mm

Jinko Solar Tiger Neo 72-cell 590W N-type TOPCon high efficiency modules

Product Features
Higher output power (590W).
Multi busbar technology ensuring reliability.
Enhanced tolerance for mechanical load.
Better shaing tolerance.
Lower levelized cost of energy (LCOE).

12 Year-Product Warranty 30-Year Linear Power Warranty

The Tiger Neo 590Wp is a 590 W class solar module from Jinko’s Tiger Neo series that leverages TOPCon N-type monocrystalline cell technology, which is known for higher efficiency and better long-term performance compared with traditional PERC cells. These panels typically feature multi-busbar design to improve current collection and overall module reliability. With a rated power of 590 Wp and efficiencies around 22.8 %, this panel is capable of generating substantial energy per unit area — especially useful where roof or ground space is at a premium.

Mechanically, the panel has a robust build with an anodised aluminium frame and standard MC4 or compatible connectors for easy integration into most solar arrays. Typical dimensions are about 2278 mm × 1134 mm × 30 mm, and the unit weighs approximately 27 kg — making it fairly manageable relative to its output class.

In terms of operating characteristics, it produces around 43.7 V at maximum power (Vmp) and 13.5 A (Imp), with open-circuit and short-circuit voltages around 52.6 V and 14.1 A respectively. Temperature coefficients of around –0.29 %/°C imply moderate power drop in high heat conditions, reflecting commercial-grade thermal design.

Warranty coverage typically includes a 12-year product warranty and a 30-year linear power output warranty, ensuring long-term support and predictable performance degradation — a key factor when calculating lifetime energy yield and return on investment for solar installations.

Overall, the Tiger Neo 590Wp panel is positioned as a high-power, efficient module with solid electrical and mechanical characteristics, suited for modern solar arrays where maximizing output per panel is important. If you want deeper insights into related models or alternatives, just let me know!
