50kW SolisS6 Hybrid Inverter
50kW SolisS6 Hybrid Inverter
This series of products support independent generator port and parallel operation of multiple products;
With 4 MPPT, and 40A/MPPT current input capacity, can maximize the advantages of rooftop PV power, the product has independent generator port, high current charging and discharging capacity, and a variety of flexible load capacity: including UPS level switching, adapt to three-phase unbalanced load and half-wave load, etc., make the energy supply is very reliable.
Three Phase High Voltage Energy Storage Inverter
Leading Features
- 2 seconds of 160% overload capability
- Supports Peakshaving features in “self-use” and “generator” modes
- Supports Unbalanced and Half-Wave Loads on both the Grid and Backup Port
- Support 200% DC/AC ratio, make full use of PV charging, provide long backup hours
- Battery real-time monitoring , remote upgrade, and battery healing function to prolong battery life
- Supports a maximum input current of 20 A, making it ideal for all high-power PV modules from any brand
- A wide battery voltage range accommodates the prevalent high-voltage lithium batteries found in the market
- Battery charging/discharging current 140A/70A+70A, suitable for 280Ah cell standard 0.5C application condition
Features:
- Allowable PV of up to 100kW, on the 180-1000V MPPT.
- 4-MPPTs, rated at 40A each, with 2-string inputs each allowing for 8 strings of high power/current PV modules.
- Supports Grid and Generator AC inputs.
- Parallel up to 3 x inverters for up to 150kW of back-up load.
- Battery Charge and Discharge current of up to 140A.
- UPS transfer time of less than 10ms.
- 160% surge power for 2s to accommodate inductive loads.
- Integrated AFCI (DC arc-fault circuit protection) – mitigating fire risks.
- LCD display and remote firmware upgrades with included S4 Wi-Fi/LAN Stick and Solis Cloud support/monitoring.
- Solis reliability with 5-year warranty. (extendable to 10/15/20-years)
SA:
- NRS-097 certified and CoCT approved.
- Parallel up to 6 units – awaiting firmware upgrade ETA July.
